Electric Setup For The
55" Bertrand Choupin's Ambisagrus
As Featured in The March 2025 RCM&E

Ambisagrus by Bertrand Choupin as Featured in the March Issue of RCCME

Please Note Due to having our knuckles severely rapped by the Post Office we can no longer send any kind of battery via the post. Any order containing batteries will have to be sent via courier and this will incur a minimum of a £9.99 delivery and packaging charge.
We cannot deliver batteries outside of mainland UK

This 3S Setup should provide around 3.8lbs of static thrust
with an estimated top speed of around 57MPH

Part Number	Description	Price	Quantity
PO-3535-1090	Brushless Outrunner Motor fitted with 3.5mm connectors	£28.99
4M-HESC40AV2	40A Brushless Electronic Speed controller Supplied with 3.5mm connectors on motor side and XT60 on battery side	£31.95
Spinner	57mm Diameter in Black	£7.20
Prop	Vortex 10" x 6" Propeller	£3.11
4M-175AMG-030	4pcs of 4M-175AMG-030 Mini Analog Metal Geared Servo	£34.92
PPL-60C3S-2200	3S, 2200mAh LiPo Battery 60C Fitted with XT60 Connector	£24.00
Main Undercarriage	Main Undercarriage set, includes Alloy undercarriage, pair of 4mm stub axles, 4x washers, 2x 4mm Nylock nuts, pair of 4mm wheel collets	£13.99
Main Wheels	Pair of 60mm Dia, 4mm hole Super Light Weight Hard Sponge Foam Wheels	£3.49
Nose Leg and Wheel	Nose Leg Assembly with Nose Wheel, includes Steering arm and tiller and wheel collet	£9.99
2x Snakes	2pcs of SLEC Light Weight Snake 1000mm	£3.98
Brass Extender	4pcs of Brass Extender - M2	£1.69
M2 Metal Clevises	Pack of 10pcs of M2 Ø2mm x 23mm	£3.49
Z Bend Kit Ailerons)	Pack of 4pcs of 1.2mm, 200mm Z Bend Kit	£3.99
Surface Horns	Surface Horn -Small 13.5×16mm	£1.00
Blenderm Hinge Tape	1pcs of 3M Blenderm Hinge Tape, 25mm x 4500mm	£3.99
Wing Bolt Kit Claw Nuts	2 x of M5 Nylon Wing Bolts, 35mm 2 x Steel M5 T Nuts	£2.99

This 4S Setup should provide around 4.7lbs of static thrust
with an estimated top speed of around 62MPH

Part Number	Description	Price	Quantity
PO-3547-800	Brushless Outrunner Motor	£35.99
4M-HESC50AV2	50A Brushless Electronic Speed controller Supplied with 3.5mm connectors on motor side and XT60 on battery side	£57.94
JXF 11x7	JXF 11" x 7" Propeller	£9.68
4M-175AMG-030	4pcs of 4M-175AMG-030 Mini Analog Metal Geared Servo	£34.92
PPL-60C4S-2200	4S, 2200mAh LiPo Battery 60C	£33.50
