Electric Setup For The
46" Chris Foss WOT-KNOT
As Featured in The Jan 2025 RCM&E

Designed by	Chris Foss
Model Name	WOT-KNOT
Wingspan	1168mm / 46"
Flying Weight	TBA



Please Note Due to having our knuckles severely rapped by the Post Office we can no longer send any kind of battery via the post. Any order containing batteries will have to be sent via courier and this will incur a minimum of a £9.99 delivery and packaging charge.
We cannot deliver batteries outside of mainland UK

This 3S Setup should provide around 3.8lbs of static thrust
with an estimated top speed of around 57MPH

Part Number	Description	Price	Quantity
PO-3547-960	Brushless Outrunner Motor	£35.99
4M-HESC50AV2	50A Brushless Electronic Speed controller Supplied with 3.5mm connectors on motor side and XT60 on battery side	£57.94
JXF 11x7	JXF 11" x 7" Propeller	£9.68
4M-175AMG-030	4pcs of 4M-175AMG-030 Mini Analog Metal Geared Servo	£34.92
PPL-60C3S-2200	3S, 2200mAh LiPo Battery 60C	£24.00



This 4S Setup should provide around 4.7lbs of static thrust
with an estimated top speed of around 62MPH

Part Number	Description	Price	Quantity
PO-3547-800	Brushless Outrunner Motor	£35.99
4M-HESC50AV2	50A Brushless Electronic Speed controller Supplied with 3.5mm connectors on motor side and XT60 on battery side	£57.94
JXF 11x7	JXF 11" x 7" Propeller	£9.68
4M-175AMG-030	4pcs of 4M-175AMG-030 Mini Analog Metal Geared Servo	£34.92
PPL-60C4S-2200	4S, 2200mAh LiPo Battery 60C	£33.50
