Motor Setup for 76" Airbus A400M by Tony Nijhuis


   Tony Nijhuis Airbus A400M

Click here to visit Tony Nijhuis Designs

Motor comes with 3.5mm male connectors already fitted
plus the mating female halves

Dia Length Weight Shaft Diameter
27.8mm 37mm 67g 3.175mm

How to wire up multiple brushless motors

Item Part Number Description Price Quantity
Motor 4 x
PPO-2837-1120
1120kv, 10 Wind, 288W, 2-4 LiPo
Recommended Prop up to
9" x 7.5" on 3S
£91.96
Rear Mount Set 4 x
PP-MOUNTSET28
Rear Mount and Prop Driver Set for 28 Series Motors £12.00
ESC 4 x
PP-TESC30AU
30 Amp Brushless Speed Controller £71.80
LiPo Battery 1 x
PPL-20C3S-6000
3S, 6000mAh LiPo Battery, 30C Cont, 60C Burst £70.99
  TN-COMBO-011 4 Sets of Motor + ESC + Props + Rear Mount Set + LiPo - Save £14.00 £244.35
  TN-COMBO-012 4 Sets of Motor + ESC + Props + Rear Mount Set - Save £5.00 £178.36
