Connectors
  • JST/BEC connectors are good for up to 12 Amps
  • 2mm connectors are good for up to 20 Amps
  • 3.5mm connectors are generally used for the connections between the motor and the speed controllers
  • EC3 and XT60 connectors are good for up to 35Amps
  • 4mm connectors are good for up to 70 Amps
  • XT90 and EC5 connectors are good for up to 90Amps
  • 6mm connectors are good for up to 120 Amps
  • 8mm connectors are good for up to 200 Amps
  • The Deans style connectors are good for up to 40 Amps

Click on the thumbnail photo for a larger version

  Part Number Description Price Quantity
BEC/JST connector PP-JSTCON-M 5 x Male JST/BEC Connector
with pins		 £2.99
BEC/JST connector PP-JSTCON-F 5 x Female JST/BEC Connector
with pins 		£2.99
Servo connectors PP-SERVOCON 5 X JR Servo connector can be used as a male or female connector.
Enough to make 5 extension leads 		£2.75
MaxLoc Connectors Click here for our range of
MaxLoc™ Multi Way Servo Connectors
(Previously known as Ashlock)
Servo Crimp Pliers PP-CRIMP-PLIERS Servo crimp pliers £22.50
2mm gold plated connector PP-CON20 2.0mm Gold Connectors
(5 male & 5 female)		 £3.90
PP-CON20 2.0mm Gold Connectors
(10 male & 10 female)		 £7.50
3.5mm gold plated connector PP-CON35 3.5mm Gold Connectors
(5 male & 5 female)		 £3.90
PP-CON35 3.5mm Gold Connectors
(10 male & 10 female)		 £7.50
4mm gold plated connector PP-CON40 4.0mm Gold Connectors
(5 male & 5 female)		 £3.90
PP-CON40 4.0mm Gold Connectors
(10 male & 10 female)		 £7.50
6mm gold plated connector PP-CON60 6.0mm Gold Connectors
(5 male & 5 female)		 £5.90
PP-CON60 6.0mm Gold Connectors
(10 male & 10 female) 		£9.50
8mm gold plated connector PP-CON80 8.0mm Gold Connectors
(5 male & 5 female)		 £8.50
PP-CON80 8.0mm Gold Connectors
(10 male & 10 female) 		£15.00
Deans Style connector DEAN Deans Style connectors
(5 male & 5 female)		 £4.50
DEAN Deans Style connectors
(10 male & 10 female) 		£8.50
4mm connector with cover DEAN-Wall Deans Style connector
Wall Mounting up to 16mm Thick
(Supplied with connector) 		£2.99
XT 60 Connector Wall Fixing DEAN-Wall-Metal Deans Style connector
Wall Mounting - Metal
(with pair of deans style connector) 		£5.99
4mm connector with cover PP-4MM-COVER 1 pack of 2 pair of High Quality 4mm Gold bullet connector with hard plastic cover £2.00
4mm Banana plug PP-4MM-RED-BLK High Quality 4mm banana plugs
(5 red & 5 black)		 £4.00
4mm banana socket PP-4MM-SOCKET High Quality 4mm jack sockets
(5 red & 5 black)		 £3.90
EC3 Connector EC3 E-Flite EC3 type connectors
(5 off male & 5 off female)		 £5.50
EC5 Connector EC5 E-Flite EC5 type connectors
(5 off male & 5 off female)		 £11.49
XT 30 Connector XT30 XT-30 type connectors
(5 off male & 5 off female)		 £5.00
XT60H Connector XT60H XT-60 type connectors
(5 off male & 5 off female)
(Comes with terminal covers)		 £5.99
XT60H Connector XT60 Cover 5 off XT60 Battery (Female) covers £1.99
XT 60 Connector with Bracket XT60E XT-60 type connector
(1 off with Bracket)		 £1.25
XT 60 Connector Wall Fixing XT60-Wall XT-60 type connector
Wall Mounting up to 16mm Thick 		£2.99
XT 60 Connector Wall Fixing XT60-PARALLEL XT-60 Parallel Adapter £4.99
XT90E-M connector
 XT90E-M XT90E-M type connector
(1 off with Bracket)		 £1.75
XT-90 connector
 XT90 1 Pair of XT-90 Connector
(1 off male & 1 off female)		 £2.99
Anti Spark XT-90 connector
 XT90-AS 1 Pair of Anti Spark XT-90 Connector
(1 off male & 1 off female)		 £3.70
XT 60 Connector Wall Fixing XT90-PARALLEL XT90 Parallel Adapter £5.99
Anti Spark SA150 connector
 AS150 1 Pairs of Anti Spark AS150 connectors. It features an insulated tip to stop big sparks from higher voltage applications.
 £3.99
Multiplex connector MULTIPLEX 5 Pairs of Multiplex Style connectors
(5 off male & 5 off female)		 £7.99
Multiplex connector MULTIPLEX-B 5 Pairs of Multiplex Style connectors with mounting bracket
(5 off male & 5 off female)		 £8.50 Out of Stock
